| Models | ESP500-960 | ESP500-1500 | ESP1000-2015 |
| AC output power | 500VA/500W | 500VA/500W | 500VA/500W |
| Peak power(ms) | 1000VA | 1000VA | 1000VA |
| AC input | |||
| Input voltage | 145-265Vac±5% | ||
| Input frequency | 45-65Hz | ||
| EPS ac output | |||
| Output phase | L+N+PE | ||
| Output voltage | 220V/230Vac±5% | ||
| Output frequency | 50/60Hz±1%（Inverter mode） | ||
| Output waveform | Pure sine wave | ||
| Output power | 500W | ||
| PV charging&AC charging | |||
| Max pv input power | 350W/750W | ||
| Max pv voltage(voc) | 55Vdc | ||
| Optimal tracking voltage(vmp) | 18-30V/36-45Vdc | ||
| Max pv charging current | 30A | ||
| Max ac charging current | 10A | ||
| Battery cluster | |||
| Battery type | GEL Battery/LiFePO4 | ||
| Battery voltage | 12V/12.8V/25.6V | ||
| Battery capacity | 960WH-2015WH | ||
| Other information | |||
| 5VUSB Max | 24W 5VUSB*2 QC3.0 | ||
| 12VDC Optional | |||
| Conversion time | ≦4Ms | ||
| Size(mm) | 480*260*490mm | ||
| Communication | RS485/WIFI/GPRS (Optional） | ||
| Installation mode | floor mounted | ||
| Ambient Temperature | -10℃-50℃ | ||
Off-grid system Connection diagram
 |
Built-in battery |
| Power frequency pure sine wave | |
| 500W output power | |
| Solar inverter/ups | |
| Integrated power supply system |
ESP SYSTEM Application
- ●Household power supply system
- ●Outdoor work
- ●Touring car power
- ●Outdoor live broadcast
- ●Communication base station
