| Models | ESP6000-9600 | ESP6000-10240 |
| AC output power | 5000VA/5000W | 5000VA/5000W |
| Peak power(ms) | 15000VA | 15000VA |
| AC input | ||
| Input voltage | 165-265Vac±5% | |
| Input frequency | 45-65Hz | |
| EPS ac output | ||
| Output phase | L+N+PE | |
| Output voltage | 220V/230Vac±5% | |
| Output frequency | 50/60Hz±1%（Inverter mode） | |
| Output waveform | Pure sine wave | |
| Output power | 6000W | |
| PV charging&AC charging | ||
| Max pv input power | 3000W | 3200W |
| Max pv voltage(voc) | 100Vdc | 150Vdc |
| Optimal tracking voltage(vmp) | 65-72Vdc | 65-110Vdc |
| Max pv charging current | 60A | |
| Max ac charging current | 15A | |
| Battery cluster | ||
| Battery type | GEL Battery | LiFePO4 |
| Battery voltage | 48V |
51.2V
|
| Battery capacity | 9600WH |
10240WH
|
| Other information | ||
| 5VUSB | Max 24W 5VUSB*3 QC3.0 | |
| 12VDC | 5521-12V3A*2 | |
| Conversion time | ≦4Ms | |
| Size(mm) | 610*550*1010mm | |
| Communication | RS485/WIFI/GPRS (Optional） | |
| Installation mode | floor mounted | |
| Ambient Temperature | -10℃-50℃ | |
Off-grid system Connection diagram
 |
Built-in battery |
| Power frequency pure sine wave | |
| 6000W output power | |
| Solar inverter/ups | |
| Lightning surge protection | |
| Integrated power supply system |
ESP SYSTEM Application
- ●Household power supply system
- ●Electricity for fishing rafts
- ●Nomadic
- ●Impact load
- ●3P Air conditioner
